JBL Synthesis 4349
The JBL Studio Monitor 4349 is a compact, high performance bookshelf loudspeaker built around patented JBL acoustic technologies. Unparalleled detail, power, and dynamics are delivered by the D2415K dual 1.5 inch compression driver.
This revolutionary driver is mated to a large format horn based upon the latest High Definition Imaging (HDI™) geometry for controlled directivity and seamless integration with the woofer. A 12 inch, cast frame Pure pulp cone woofer delivers outstanding bass response and impact that combines with the compression driver and horn to render music with authority and accuracy not possible with traditional loudspeaker designs.
Top Features:
• D2415K, Dual 1.5 inch/37.9mm annular ring, Teonex ® diaphragm compression driver
• HDI™ High Definition Imaging geometry horn
• 12" (300mm), Cast frame, Pure Pulp cone woofer (JW300PG 8)
• HF and UHF level controls for system tuning
• Satin Walnut or Black Walnut wood veneer finish
General Specifications
• Type: 2-way monitor loudspeaker
• Low Frequency Driver: 12" (300mm) Pure Pulp cone woofer (JW300PG-8)
• High Frequency Driver: D2415K, 1.5-inch (37.9mm) annular ring, Teonex® diaphragm compression driver with advanced HDI™ geometry horn molded in Sonoglass
• Recommended Amplifier Power: 25 - 200 WRMS
• Impedance: 8 Ohm
• Loudspeaker Sensitivity: 91 dB/2.83V/1m
• Frequency Response: 32 - 25 000Hz (-6 dB)
• Coverage Angle, -6 dB @ 20kHz: 80 x 70 Degrees (Hor x Vert)
• Coverage Angle, -6 dB @ 10kHz: 100 x 100 Degrees (Hor x Vert)
• Crossover Frequency: 1.5 kHz
• Enclosure Type: V-braced front-ported cabinet
• Grille Feature: Monitor style to match horn mating features
• Controls: HF and UHF tone controls
• Input Type: Dual sets of gold-plated binding posts with shorting straps
Dimensions:
• Product Weight: 37.7 kg
• Dimensions with grille: (HxBxD) 737x445x318mm
Övrigt:
• Warranty: 5 Years
